What is the name of a multi-touch screen for a touch-join interactive wall?

Views: 0     Author: Nursen     Publish Time: 2025-11-25      Origin: https://www.luphitouch.com

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
sharethis sharing button

What is called a touch splicing wall, and is it the industry's generic term for touch splicing screens?

What is the name of a multi-touch screen for a touch-join interactive wall?

The so-called touch splicing interactive wall can be roughly called: splicing screen infrared touch frame, touch screen splicing screen, splicing screen infrared frame, infrared touch screen splicing screen, LCD splice touch frame, touch control splicing screen, touch control screen splicing wall, splicing wall touch screen, infrared frame splicing screen, large size splice touch screen, large size touch screen splicing screen, DID splice touch screen, splice touch screen, narrow side touch screen splicing screen, narrow side splicing screen touch screen, touch control splicing wall, interactive splice touch screen, interactive touch splicing screen, conference touch splicing screen, (exhibition hall splicing screen touch screen, large size projection splice touch screen, etc.; many names are called according to on-site applications.

A touch screen video wall is a combination of a video wall and a touch screen, consisting of two ultra-narrow edge video walls custom-made by the  factory. It integrates tempered glass, video wall processors, matrix processors, HDMI distributors, multi-screen assistants, multi-screen display cards, audio systems, and computer hosts into an interactive touch screen video wall display device. Finally, it is installed with matching digital creative display software to achieve human-computer interaction integration of auditory, visual, and tactile senses in digital exhibition halls, exhibition halls, digital exhibition halls, enterprise exhibition halls, planning exhibition halls, urban planning museums, creative centers, O2O experience centers, and achievement exhibition halls on site.

Introduction to Multi-touch Video Wall, Infrared Touch Technology Principle:

Principle of infrared touch screen: Taking the large-size infrared multi-touch screen, its working principle is to arrange a dense infrared matrix in the front of the screen and in the Y direction. By constantly scanning whether any infrared rays are blocked by objects, it detects and locates the user's infrared touch frame, touch splicing screen. As shown in the figure below, the multi-touch screen installs an outer frame in front of the display, with a circuit board designed inside the outer frame, thus arranging infrared emitters and infrared receivers along the four sides of the screen, forming a horizontal and vertical cross infrared matrix one by one. After each scan, if all the infrared pairs are connected, it indicates that everything is normal and there is no touch. When touched, fingers or other objects will block the horizontal and vertical infrared rays passing through this coordinate position. When the X or Y axis touch screen scans and finds and confirms that an infrared ray is interrupted, it indicates that there may be a touch, and immediately switches to another axis coordinate for scanning. If another axis also has an interrupted infrared ray, it indicates that a touch frame is found, and after calculation, the position of the touch point on the screen is determined.
